ABB DCS Equipment

E108 - TU 706F, FBP Terminal Unit, 24 VDCSpring-type

TK857V003 RCU Link Cable
Length = 0.3 m.
Used with BC820.

TK856 RCU Control Link Cable
Length = 1.0 m.
Used as: RCU Control Link Cable

TK855, RCU Data Link Cable

TK851V010 Connection Cable
Length = 1.0 m.
Used as:
- RCU Link Cable
- BC810 Interconnection Cable

TK850V007 CEX-Bus Extension Cable
Length = 0.7 m
Use of TK850V007 needs TK851 as CEX-bus terminator.

Diagnostics Cable, 5 m
Identical with DSU 141.

Diagnostics Cable, 10 m
Identical with DSU 141.

TK 831F, CAN Cable, 3 channel, integral connectors, 0.5m

Serial Cable (2 channel), integral connectors, 0.5 m
Identical with DFA 021.
Connection FI 820F to Terminal Block TB 870F.

CAN Cable, open end, ferrules, 3 m
3 x 2 x 0.25 mm²,
The cable is used for connection of Freelance Rack I/O to the CI 910F CAN Bus Module.

TK 809F, Supply Cable, 115 / 230 VAC, US plug, 2 meter, For SA 801F and SA 811F

TK 807F, Supply Cable, 115 / 230 VAC, ferrules, 2 meter

TK 802F, Supply Cable 24V, ferrules, 2m

TD 951F, Display Unit, 64 x 128 Dot matrix LCD, Keypad

TB853, RCU Control Link Terminator

TB852, RCU Link Terminator

TB851 CEX-Bus Terminator
With 25-pin DB25S female connector. With screw fixing.
When Communication Interface units are mounted on
adjacent DIN rails, they are connected by means of a CEX-Bus
extension cable (TK850) and terminated using a TB851
CEX-Bus terminator.

TB850 CEX-Bus Terminator
With 25-pin DB25P male connector. With screw fixing.
A TB850 CEX-Bus terminator must always be installed on the
last unit on the CEX bus.

TB 870F, Terminal Block for serial interface

TA521, Battery for RAM buffering, Button Cell, Lithium, For PM 783F

TA 924F, Dummy Coupler Module, cover for unused slots

TA 724F, Dummy Coupler Module, cover for unused slots

SD 812F-Z, Power Supply 24Vdc

SD 812F, Power Supply, Input voltage 24Vdc, Output voltage 5Vdc
