ABB 800XA

TK857V003 RCU Link Cable
Length = 0.3 m.
Used with BC820.

TK856 RCU Control Link Cable
Length = 1.0 m.
Used as: RCU Control Link Cable

TK855, RCU Data Link Cable

TK851V010 Connection Cable
Length = 1.0 m.
Used as:
- RCU Link Cable
- BC810 Interconnection Cable

TK850V007 CEX-Bus Extension Cable
Length = 0.7 m
Use of TK850V007 needs TK851 as CEX-bus terminator.

TB853, RCU Control Link Terminator

TB852, RCU Link Terminator

TB851 CEX-Bus Terminator
With 25-pin DB25S female connector. With screw fixing.
When Communication Interface units are mounted on
adjacent DIN rails, they are connected by means of a CEX-Bus
extension cable (TK850) and terminated using a TB851
CEX-Bus terminator.

TB850 CEX-Bus Terminator
With 25-pin DB25P male connector. With screw fixing.
A TB850 CEX-Bus terminator must always be installed on the
last unit on the CEX bus.

SB822, External DIN-rail mounted rechargeable battery unit

450 Mhz and 256 MB. Package including:
- 2 pcs PM891K01 Processor Unit
- 1 pcs TK850V007 CEX-bus Extension Cable
- 1 pcs TK855 RCU Data Link Cable
- 1 pcs TK856 RCU Control Link Cable
- No license included

450 Mhz and 256 MB. Package including:
- PM891 CPU Module
- TB850, CEX-bus terminator
- TB853, RCU Control Link Terminator
- No license included

PM866AK02
133 Mhz and 64 MB. Package including:
- 2 pcs PM866A, CPU
- 2 pcs TP830, Baseplate, width =115mm
- 2 pcs TB807, ModuleBus terminator
- 1 pcs TK850, CEX-bus expansion cable
- 1 pcs TB851, RCU-Link cable
- 2 pcs Battery for memory backup (4943013-6)
- No license included

133 Mhz and 64 MB. Package including:
- PM866A, CPU
- TP830, Baseplate, width =115mm
- TB850, CEX-bus terminator
- TB807, ModuleBus terminator
- TB852, RCU-Link terminator
- Battery for memory backup (4943013-6)
- No license included

PM862K02, Redundant Processor Unit, 2 pcs PM862 CPU, 32 Mb memory, 67 MHz cpu clock

67 Mhz and 32 MB. Package including:
- PM862, CPU
- TP830, Baseplate, width =115mm
- TB850, CEX-bus terminator
- TB807, ModuleBus terminator
- TB852, RCU-Link terminator
- Battery for memory backup (4943013-6)
- No license included
Only compatible with 800xA 6.0.2, Compact Control Builder
6.0.0-1 and onwards.
Please see Product Update for more information.

Package including:
PM861A, CPU TP830, Baseplate, width =115mm TB850, CEX-bus terminator TB807, ModuleBus terminator TB852, RCU-Link terminator Battery for memory backup (4943013-6

PM860AK01 Processor Unit, 16 Mb memory, 48 MHz cpu clock, 2 ethernet ports, 2 serial RJ45 ports

33 Mhz and 16 MB. Package including:
- 2 pcs PM858, CPU
- 2 pcs TP830, Baseplate, width =115mm
- 2 pcs TB807, ModuleBus terminator
- 1 pcs TK850, CEX-bus expansion cable
- 1 pcs TK851, RCU-Link cable
- 2 pcs Battery for memory backup (4943013-6)
- No license included
Only compatible with 800xA 6.0.2, Compact Control Builder
6.0.0-1 and onwards.
Please see Product Update for more information.

33 Mhz and16 MB. Package including:
- PM858, CPU
- TP830, Baseplate, width =115mm
- TB850, CEX-bus terminator
- TB807, ModuleBus terminator
- TB852, RCU-Link terminator
- Battery for memory backup (4943013-6)
- No license included
Only compatible with 800xA 6.0.2, Compact Control Builder
6.0.0-1 and onwards.
Please see Product Update for more information.

24 Mhz and 12 MB. Package including:
- PM856A, CPU
- TP830, Baseplate, width=115 mm
- TB850, CEX-bus terminator
- TB807, ModuleBus terminator
- Battery for memory backup (4943013-6)
- No license included

PM851AK01, Processor Unit, 24Mhz clock frequency, 12MB RAM

CI855K01 MB 300 Interface
Package including:
- CI855, MB300 Interface Module
- TP853, Base plate

Expansion Compact Flash memory for Panel 800 Version 5.
512 MB

LD 800DN Linking Device
EtherNet/IP to DeviceNet
Package including:
1 pcs LD 800DN
1 pcs Installation Guide
2 pcs Termination resistors for DeviceNet, 1/4 W, 121 Ohm.
G1 compliant
Only to be used with CI873 Communication Interface.
